BRAVO MPPT Solar Charge Controller | 40A, 50A
SKU: RS-MPPT40P
$199.99
/
Shipping calculated at checkout.
Shipping
This product is shipped directly from the manufacturer. Shipping times may vary, and the manufacturer's warranty applies.
Specifications & Downloads
Features
- MPPT
- Tracking Efficiency Above 99.5%
- Charge Conversion Efficiency as high as 98%
- 12V/24V DC System Self-Adaptation
- Reverse Discharge Protection
- Targeted for Accuracy
- Overvoltage Protection
- Common Negative Connection
- Charging Data Storage
- Conformal Coating For Inside Board
- In-house Design And Manufacture
- Extensive Internal Electronics, In-Circuit Protections, And Safety Protections
- Targeted For Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
- Targeted For Lithium Batteries: LiFePO4, LTO (Lithium Titanium Oxide), LCO Batteries Type Selections
Specifications
- System Nominal Voltage: 12/24V Auto
- Max. PV Open Circuit Voltage: 100V DC
- Charging Technology: MPPT
- Max PV Charging Current: 40A
- Max. Recommended PV Input Power: 600 Watt (12V) / 1200 Watt (24V)
- Charge Conversion Efficiency: ≤98%
- MPPT Tracking Efficiency: >99.5%
- Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
- Housing Case Color: Black / Grey
- IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
- Net Weight: 1.17kg / 2.58lb
- Dimensions (L*W*H): 195*142*74 mm / 7.7*5.5*2.9 in
Features
- True MPPT
- Tracking Efficiency Above 99.5%
- Charge Conversion Efficiency as High as 98%
- 12V / 24V DC System Self-Adaptation
- Reverse Discharge Protection
- Targeted for Accuracy
- Overvoltage Protection
- Common Negative Connection
- Charging Data Storage
- Conformal Coating for Inside Board
- In-house Design and Manufacture
- Extensive Internal Electronics, In-Circuit Protections, and Safety Protections
- Targeted for Lead Acid Batteries: Gel, AGM, WET, CRYSTAL, CALCIUM Batteries Type Selections
- Targeted for Lithium Batteries: LiFePO4, LTO (Lithium Titanate Oxide), LCO Batteries Type Selections
Specifications
- System Nominal Voltage: 12/24V Auto
- Max PV Open Circuit Voltage: 100V DC
- Charging Technology: MPPT
- Max PV Charging Current: 50A
- Max. Recommended PV Input Power: 700 Watt (12V) / 1400 Watt (24V)
- Charge Conversion Efficiency: ≤98%
- MPPT Tracking Efficiency: >99.5%
- Battery Type Preset: Crystal, Gel, AGM, WET, Calcium / LCO, LFP, LTO
- Housing Case Color: Black / Grey
- IP Grade: IP43 for Inside PCBA, IP22 for Connection Area
- Net Weight: 1.40kg / 3.09lb
- Dimensions (L*W*H): 195*140*74 mm / 7.7*5.5*2.9 in
